ULTRON ES-CD

ULTRON ES-CD and ULTRON ES-PhCD are enantiomeric separation columns chemically bonded with

β-cyclodextrin (CD) and phenylcarbamated β-cyclodextrin (PhCD), respectively.

■ Features

1. Capable of chiral separations of hydrophobic cyclic compounds.
2. Both reverse and normal phase eluents can be used.
3. Chiral separations of a wide range of compounds are possible using these two types of columns.
4. Display superior stability and durability.

■ Characteristics

① ULTRON ES-CD and ULTRON ES-PhCD are effective for the enantiomeric separation of hydrophobic

cyclic compounds.

② Mobile phase of both reverse-phase and normal-phase modes can be used for the separation.

③ A wide range of enantiomeric compounds can be separated with ULTRON ES-CD or ULTRON ES-PhCD.

④ The columns show excellent stability and durability.

■ Applications

・Pharmaceutical compounds, Pesticides and Organic compounds

■ Applications

・ Analysis of carteolol hydrochloride using the ULTRON ES-PhCD-T

Shown below is a reversed-phase analysis of carteolol hydrochloride performed using the ULTRON ES-PhCD-T.

Column: ULTRON ES-PhCD-T (5 μm)

Column temp.: 25℃

Column size: 150 mm L x 6.0 mm I.D.

Detection: UV-220 nm

Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 60/40

Sample: 200 mg/L (in mobile phase)

Flow rate: 1.0 mL/min

Injection vol.: 2 μL

※Please contact us for application data sheets containing examples of separations of optical isomers obtained using ULTRON ES-OVM, ES-CD, ES-PhCD, ES-PEPSIN, and ES-BSA columns.
